SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B) - 1

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B) - 1

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B)

:

Product Code : o386098

: T531300

14.1403 USD + VAT

Featured Information

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B)

Out Of Stock

Notify me when its in stock

Buy MORE, Pay LESS

Quantity

Discount

1 - 9

%0

10 - 19

%12

20 - 40

%18

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B)

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B) Description

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B) SGR282ZK VAR1 24VDC is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/DC and coil resistance of 822 Ohms. Features a coil power of 700mW and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 30.20mm, width 12.70mm, and height 25.60mm.Manufactured by ELESTA and compliant with ROHS standards. Packaged as BOX for convenience.

SGR282ZK VAR1 24VDC RELAY FORCEGUIDED 8A 24VDC (1 Form A/1 Form B) Technical Specifications

Manufacturer: ELESTA
RelayType: Relay Forcibly Guided
Series: SGR282ZK
MountingType: THT
ContactForm: DPST-NO/NC (1 Form A/1 Form B)
CoilType: Non Latching
ContactCurrent(Nom): 8A
ContactCurrent(Max):
CoilVoltage: 24VDC
CoilCurrent: 29.10mA
ContactVoltage: 250VAC/DC
CoilResistance: 822 Ohms
CoilPower: 700mW
OperatingTemperature: -40°C~+70°C
NumberofPins: 6 Pin
Length: 30.20mm
Width: 12.70mm
Height: 25.60mm
Rohs: ROHS
Packaging: BOX

You can click for product datasheet.
