SIF212 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/1 Form B)

SIF212 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/1 Form B) Description

SIF212 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/1 Form B) SIF212 12VDC is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/DC and coil resistance of 240 Ohms. Features a coil power of 600mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 33.70mm, width 29.40mm, and height 10.90mm.Manufactured by ELESTA and compliant with ROHS standards. Packaged as BOX for convenience.

SIF212 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/1 Form B) Technical Specifications

• Manufacturer: ELESTA
• RelayType: Relay Forcibly Guided
• Series: SIF3
• MountingType: THT
• ContactForm: 3PST-NO/NC (2 Form A/1 Form B)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent: 50mA
• ContactVoltage: 250VAC/DC
• CoilResistance: 240 Ohms
• CoilPower: 600mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 8 Pin
• Length: 33.70mm
• Width: 29.40mm
• Height: 10.90mm
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
