JS-12E-K RELAY POWER 8A 12VDC 1P FUJITSU

JS-12E-K RELAY POWER 8A 12VDC 1P FUJITSU Description

JS-12E-K RELAY POWER 8A 12VDC 1P FUJITSU JS-12E-K is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/24VDC and coil resistance of 660 Ohms. Features a coil power of 220mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 29.00mm, width 10.00mm, and height 12.50mm.Manufactured by FUJITSU and compliant with ROHS standards. Packaged as TUBE for convenience.

JS-12E-K RELAY POWER 8A 12VDC 1P FUJITSU Technical Specifications

• Manufacturer: FUJITSU
• RelayType: Relay Power
• Series: JS
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 8A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent:
• ContactVoltage: 250VAC/24VDC
• CoilResistance: 660 Ohms
• CoilPower: 220mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 5 Pin
• Length: 29.00mm
• Width: 10.00mm
• Height: 12.50mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
