FH28-1CST-DC12V RELAY POWER 5A 12V ULTRA MINI

FH28-1CST-DC12V RELAY POWER 5A 12V ULTRA MINI Description

FH28-1CST-DC12V RELAY POWER 5A 12V ULTRA MINI FH28-1CST-DC12V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/16VDC and coil resistance of 240 Ohms. Features a coil power of 600mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 15.50mm, width 12.00mm, and height 13.70mm.Manufactured by FANHAR and compliant with ROHS standards. Packaged as TRAY for convenience.

FH28-1CST-DC12V RELAY POWER 5A 12V ULTRA MINI Technical Specifications

• Manufacturer: FANHAR
• RelayType: Relay Power
• Series: FH28
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 5A
• ContactCurrent(Max): 20A
• CoilVoltage: 12VDC
• CoilCurrent: 50mA
• ContactVoltage: 250VAC/16VDC
• CoilResistance: 240 Ohms
• CoilPower: 600mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 5 Pin
• Length: 15.50mm
• Width: 12.00mm
• Height: 13.70mm
• Rohs: ROHS
• Packaging: TRAY

---

You can click for product datasheet.
