DS2E-SL2-DC5V RELAY 2A 5DC 2PNC TELECOM LATCHING TYPE PANASONIC

DS2E-SL2-DC5V RELAY 2A 5DC 2PNC TELECOM LATCHING TYPE PANASONIC Description

DS2E-SL2-DC5V RELAY 2A 5DC 2PNC TELECOM LATCHING TYPE PANASONIC DS2E-SL2-DC5V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/220VDC - Max and coil resistance of 139 Ohms. Features a coil power of 180mW and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 20.00mm, width 9.90mm, and height 9.90mm.Manufactured by PANASONIC COMP. and compliant with ROHS standards. Packaged as TUBE for convenience.

DS2E-SL2-DC5V RELAY 2A 5DC 2PNC TELECOM LATCHING TYPE PANASONIC Technical Specifications

• Manufacturer: PANASONIC COMP.
• RelayType: Relay General
• Series: DS
• MountingType: THT
• ContactForm: DPDT (2 Form C)
• CoilType: Latching, Dual Coil
• ContactCurrent(Nom): 2A
• ContactCurrent(Max):
• CoilVoltage: 5VDC
• CoilCurrent: 36mA
• ContactVoltage: 250VAC/220VDC - Max
• CoilResistance: 139 Ohms
• CoilPower: 180mW
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 10 Pin
• Length: 20.00mm
• Width: 9.90mm
• Height: 9.90mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
