7-1393243-9 RELAY GEN PURPOSE DPDT 8A 230V

7-1393243-9 RELAY GEN PURPOSE DPDT 8A 230V Description

7-1393243-9 RELAY GEN PURPOSE DPDT 8A 230V 7-1393243-9 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 400VAC - Max and coil resistance of 32.50K Ohms. Features a coil power of nan and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 29.00mm, width 12.70mm, and height 15.70mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

7-1393243-9 RELAY GEN PURPOSE DPDT 8A 230V Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay Power
• Series: RT2
• MountingType: THT
• ContactForm: DPDT (2 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 8A
• ContactCurrent(Max): 10A
• CoilVoltage: 230VAC
• CoilCurrent:
• ContactVoltage: 400VAC - Max
• CoilResistance: 32.50K Ohms
• CoilPower:
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 8 Pin
• Length: 29.00mm
• Width: 12.70mm
• Height: 15.70mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
