T20161-W64SC1C2FB5B7-AB0 LED SMD 2016 CW 6500K min.22-26LM@65mA

T20161-W64SC1C2FB5B7-AB0 LED SMD 2016 CW 6500K min.22-26LM@65mA Description

T20161-W64SC1C2FB5B7-AB0 LED SMD 2016 CW 6500K min.22-26LM@65mA The T20161-W64SC1C2FB5B7-AB0 is a high-quality product offering LED SMD 2016 CW 6500K min.22-26LM@65mA. With a shrink ratio of N/A and -40°C~+85°C operating temperature, it provides reliability in various applications.

T20161-W64SC1C2FB5B7-AB0 LED SMD 2016 CW 6500K min.22-26LM@65mA Technical Specifications

• Manufacturer: RUNLITE
• Color: Cool White
• MountingType: SMT
• Package/Case: 2016
• MountingStyle: Top View
• MaxPower: 225mW
• CCT: 6500K
• Luminous Flux(25°C): 22-26lm
• Luminous Flux(85°C):
• Luminous Intensity(25°C):
• ForwardVoltage: 3.00-3.30V @ 25°C
• Forward Current: 75mA
• TestCurrent: 60mA
• CRI:
• ViewAngle: 120°
• ThermalResistance: 85°C/W
• Diameter:
• Length: 2.00mm
• Width: 1.60mm
• Height: 0.55mm
• OperatingTemperature: -40°C~+85°C
• Rohs: ROHS
• TAPE&REEL: TAPE&REEL
• ShrinkRatio:

---

You can click for product datasheet.
