SDT-S-124DMR,000 RELAY 10A 24VDC SPST-NO THT OEG

SDT-S-124DMR,000 RELAY 10A 24VDC SPST-NO THT OEG Description

SDT-S-124DMR,000 RELAY 10A 24VDC SPST-NO THT OEG SDT-S-124DMR,000 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC - Max and coil resistance of 1.07K Ohms. Features a coil power of 540mW and operates within a temperature range of -30°C~+70°C.Compact design with dimensions: length 24.00mm, width 10.00mm, and height 25.00mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

SDT-S-124DMR,000 RELAY 10A 24VDC SPST-NO THT OEG Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay General
• Series: SDT-R
• MountingType: THT
• ContactForm: SPST-NO (1 Form A)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 24VDC
• CoilCurrent: 22.50mA
• ContactVoltage: 250VAC/30VDC - Max
• CoilResistance: 1.07K Ohms
• CoilPower: 540mW
• OperatingTemperature: -30°C~+70°C
• NumberofPins: 4 Pin
• Length: 24.00mm
• Width: 10.00mm
• Height: 25.00mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
