HLC3535F22W1EA(RA1)D2-30 LED POWER WW 3000K 120-135LM@350mA CRI:70

HLC3535F22W1EA(RA1)D2-30 LED POWER WW 3000K 120-135LM@350mA CRI:70 Description

HLC3535F22W1EA(RA1)D2-30 LED POWER WW 3000K 120-135LM@350mA CRI:70 The HLC3535F22W1EA(RA1)D2-30 is a high-quality product offering LED POWER WW 3000K 120-135LM@350mA CRI:70. With a shrink ratio of N/A and -20°C~+85°C operating temperature, it provides reliability in various applications.

HLC3535F22W1EA(RA1)D2-30 LED POWER WW 3000K 120-135LM@350mA CRI:70 Technical Specifications

• Manufacturer: HONGLITRONIC
• Color: Warm White
• MountingType: SMT
• Package/Case: 3535
• MountingStyle: Top View
• MaxPower:
• CCT: 2870-3320K
• Luminous Flux(25°C):
• Luminous Flux(85°C):
• Luminous Intensity(25°C):
• ForwardVoltage: 3.00-3.60V @ 25°C
• Forward Current: 400mA
• TestCurrent: 350mA
• CRI: 70
• ViewAngle:
• ThermalResistance: 11°C/W
• Diameter: 8.00mm
• Length:
• Width:
• Height: 5.20mm
• OperatingTemperature: -20°C~+85°C
• Rohs: ROHS
• TAPE&REEL: TAPE&REEL
• ShrinkRatio:

---

You can click for product datasheet.
