SAVLS-3014ULWC LED SMD 3014 CW 8000-10000K 9-10LM@30ma

SAVLS-3014ULWC LED SMD 3014 CW 8000-10000K 9-10LM@30ma Description

SAVLS-3014ULWC LED SMD 3014 CW 8000-10000K 9-10LM@30ma The SAVLS-3014ULWC is a high-quality product offering LED SMD 3014 CW 8000-10000K 9-10LM@30ma. With a shrink ratio of N/A and -30°C~+80°C operating temperature, it provides reliability in various applications.

SAVLS-3014ULWC LED SMD 3014 CW 8000-10000K 9-10LM@30ma Technical Specifications

• Manufacturer: FORYARD
• Color: Cool White
• MountingType: SMT
• Package/Case: 3014
• MountingStyle: Top View
• MaxPower: 105mW
• CCT: 9000K
• Luminous Flux(25°C): 6lm
• Luminous Flux(85°C):
• Luminous Intensity(25°C): 3-3.50cd
• ForwardVoltage: 3.00-3.60V @ 25°C
• Forward Current: 30mA
• TestCurrent: 30mA
• CRI:
• ViewAngle: 120°
• ThermalResistance:
• Diameter:
• Length: 3.00mm
• Width: 1.40mm
• Height: 0.80mm
• OperatingTemperature: -30°C~+80°C
• Rohs: ROHS
• TAPE&REEL: TAPE&REEL
• ShrinkRatio:

---

You can click for product datasheet.
