JQX-38F-3H-AC240V RELAY 40A 220/240VAC DRAGON

JQX-38F-3H-AC240V RELAY 40A 220/240VAC DRAGON Description

JQX-38F-3H-AC240V RELAY 40A 220/240VAC DRAGON JQX-38F-3H-AC240V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC and coil resistance of 4.03K Ohms. Features a coil power of 5VA and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 41.00mm, width 38.00mm, and height 55.30mm.Manufactured by ASIA DRAGON and compliant with ROHS standards. Packaged as TUBE for convenience.

JQX-38F-3H-AC240V RELAY 40A 220/240VAC DRAGON Technical Specifications

• Manufacturer: ASIA DRAGON
• RelayType: Relay Power
• Series: JQX-38F
• MountingType: Socket
• ContactForm: 3PST-NO (3 Form A)
• CoilType: Non Latching
• ContactCurrent(Nom): 30A
• ContactCurrent(Max): 40A
• CoilVoltage: 240VAC
• CoilCurrent:
• ContactVoltage: 250VAC/30VDC
• CoilResistance: 4.03K Ohms
• CoilPower: 5VA
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 8 Pin
• Length: 41.00mm
• Width: 38.00mm
• Height: 55.30mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
