XCR-3.579545MHZ CRYSTAL 3.579545MHZ HC49U 30pF LONG BULK TECHNICAL

XCR-3.579545MHZ CRYSTAL 3.579545MHZ HC49U 30pF LONG BULK TECHNICAL Description

XCR-3.579545MHZ CRYSTAL 3.579545MHZ HC49U 30pF LONG BULK TECHNICAL XCR-3.579545MHZ is a high-performance crystal component that operates at a frequency of 3.579545MHz with a frequency stability of ±50PPM.Features equivalent series resistance (ESR) of 100 Ohms. Compact dimensions: length 10.80mm, width 4.60mm, and height 13.00mm. Supports a temperature range of -20°C~+70°C for reliable performance. Manufactured by TECHNICAL CRYSTAL with compliance to nan standards. Packaged as BULK for convenience.

XCR-3.579545MHZ CRYSTAL 3.579545MHZ HC49U 30pF LONG BULK TECHNICAL Technical Specifications

• Manufacturer: TECHNICAL CRYSTAL
• MountingType: THT
• Series: XCR
• Package/Case: HC-49U
• Frequency: 3.579545MHz
• Capacitance: 30pF
• FrequencyTolerance: ±30PPM
• FrequencyStability: ±50PPM
• EquivalentSeriesResistance(ESR): 100 Ohms
• Applications:
• Diameter:
• Length: 10.80mm
• Width: 4.60mm
• Height: 13.00mm
• OperatingTemperature: -20°C~+70°C
• Rohs:
• Packaging: BULK

---

You can click for product datasheet.
