XCR-27.000MHZ CRYSTAL 27.000MHZ HC49U 20pF +/-30PPM RS:30 ohm

XCR-27.000MHZ CRYSTAL 27.000MHZ HC49U 20pF +/-30PPM RS:30 ohm Description

XCR-27.000MHZ CRYSTAL 27.000MHZ HC49U 20pF +/-30PPM RS:30 ohm XCR-27.000MHZ is a high-performance crystal component that operates at a frequency of 27MHz with a frequency stability of ±50PPM.Features equivalent series resistance (ESR) of 40 Ohms. Compact dimensions: length 10.80mm, width 4.60mm, and height 13.00mm. Supports a temperature range of -20°C~+70°C for reliable performance. Manufactured by TECHNICAL CRYSTAL with compliance to ROHS standards. Packaged as BULK for convenience.

XCR-27.000MHZ CRYSTAL 27.000MHZ HC49U 20pF +/-30PPM RS:30 ohm Technical Specifications

• Manufacturer: TECHNICAL CRYSTAL
• MountingType: THT
• Series: XCR
• Package/Case: HC-49U
• Frequency: 27MHz
• Capacitance: 20pF
• FrequencyTolerance: ±30PPM
• FrequencyStability: ±50PPM
• EquivalentSeriesResistance(ESR): 40 Ohms
• Applications:
• Diameter:
• Length: 10.80mm
• Width: 4.60mm
• Height: 13.00mm
• OperatingTemperature: -20°C~+70°C
• Rohs: ROHS
• Packaging: BULK

---

You can click for product datasheet.
