XCR-15.00U16B-TEC CRYSTAL 15MHZ HC49U 16PF 20ppm TB TECHNICAL

XCR-15.00U16B-TEC CRYSTAL 15MHZ HC49U 16PF 20ppm TB TECHNICAL Description

XCR-15.00U16B-TEC CRYSTAL 15MHZ HC49U 16PF 20ppm TB TECHNICAL XCR-15.00U16B-TEC is a high-performance crystal component that operates at a frequency of 15MHz with a frequency stability of ±50PPM.Features equivalent series resistance (ESR) of 35 Ohms. Compact dimensions: length 10.80mm, width 4.60mm, and height 13.00mm. Supports a temperature range of -20°C~+70°C for reliable performance. Manufactured by TECHNICAL CRYSTAL with compliance to NON ROHS standards. Packaged as TAPE&REEL for convenience.

XCR-15.00U16B-TEC CRYSTAL 15MHZ HC49U 16PF 20ppm TB TECHNICAL Technical Specifications

• Manufacturer: TECHNICAL CRYSTAL
• MountingType: THT
• Series: XCR
• Package/Case: HC-49U
• Frequency: 15MHz
• Capacitance: 16pF
• FrequencyTolerance: ±30PPM
• FrequencyStability: ±50PPM
• EquivalentSeriesResistance(ESR): 35 Ohms
• Applications:
• Diameter:
• Length: 10.80mm
• Width: 4.60mm
• Height: 13.00mm
• OperatingTemperature: -20°C~+70°C
• Rohs: NON ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
