WEX025664AWPP3N00000 OLED GRAPHIC 256X64 WHITE 2.8"

WEX025664AWPP3N00000 OLED GRAPHIC 256X64 WHITE 2.8" Description

WEX025664AWPP3N00000 OLED GRAPHIC 256X64 WHITE 2.8" WEX025664AWPP3N00000 is a reliable and high-performance graphic OLED that featuring a resolution of Passive Matrix and typical supply voltage of N/A. Designed for Passive Matrix applications, it operates within a temperature range of -40°C~+80°C.Compact design with dimensions: length 84.00mm, width 25.80mm, height 2.15mm.Manufactured by WINSTAR and compliant with ROHS standards. Packaged as BOX for convenience.

WEX025664AWPP3N00000 OLED GRAPHIC 256X64 WHITE 2.8" Technical Specifications

• Manufacturer: WINSTAR
• DisplayType: TAB
• DisplayFormat: 256x64
• Size: 2.8"
• TouchFunction: Without Touch
• EmittingColor: White
• DotSize: 0.248x0.248mm
• ViewArea: 71.10x19.26mm
• Interface: 6800, 8080, SPI
• Controller: SSD1302(COF)
• Polarizer: Polarizer
• DisplayMode: Passive Matrix
• TypicalSupplyVoltage: 3V
• DrivingMethod/Duty: 1/64
• OutlineLength: 84.00mm
• OutlineWidth: 25.80mm
• OutlineHeight: 2.15mm
• OperatingTemperature: -40°C~+80°C
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
