WEH000802ABPP5N00100 OLED CHARACTER 8X2 BLUE 1.2"

WEH000802ABPP5N00100 OLED CHARACTER 8X2 BLUE 1.2" Description

WEH000802ABPP5N00100 OLED CHARACTER 8X2 BLUE 1.2" WEH000802ABPP5N00100 is an advanced OLED character display featuring a Passive Matrix mode. It operates at a typical supply voltage of N/A and has compact outline dimensions of 58.00mm x 32.00mm x 10.00mm. With an operational temperature range of -40°C~+80°C, it ensures reliable performance under various conditions. This product is ROHS compliant and is available in TRAY packaging for secure handling.

WEH000802ABPP5N00100 OLED CHARACTER 8X2 BLUE 1.2" Technical Specifications

• Manufacturer: WINSTAR
• DisplayType: COB Character
• DisplayFormat: 8x2
• Size: 1.2"
• DotSize: 0.56x0.66mm
• ViewArea: 38.00x16.00mm
• EmittingColor: Blue
• Interface: 6800
• Controller: WS0010-TX
• Polarizer: Polarizer
• DisplayMode: Passive Matrix
• Typical SupplyVoltage: 5V
• Driving Method /Duty: 1/16
• OutlineLength: 58.00mm
• OutlineWidth: 32.00mm
• OutlineHeight: 10.00mm
• OperatingTemperature: -40°C~+80°C
• Rohs: ROHS
• Packaging:

---

You can click for product datasheet.
