V23101D 106A201 RELAY 1.25A 12VDC SPDT THT AXICOM

V23101D 106A201 RELAY 1.25A 12VDC SPDT THT AXICOM Description

V23101D 106A201 RELAY 1.25A 12VDC SPDT THT AXICOM V23101D 106A201 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 125VAC/120VDC - Max and coil resistance of 700 Ohms. Features a coil power of 206mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 15.40mm, width 10.00mm, and height 11.50mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

V23101D 106A201 RELAY 1.25A 12VDC SPDT THT AXICOM Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay General
• Series: V23101
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 1.25A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent: 17.20mA
• ContactVoltage: 125VAC/120VDC - Max
• CoilResistance: 700 Ohms
• CoilPower: 206mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 6 Pin
• Length: 15.40mm
• Width: 10.00mm
• Height: 11.50mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
