SLR222 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/2 Form B)

SLR222 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/2 Form B) Description

SLR222 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/2 Form B) SLR222 12VDC is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/DC and coil resistance of 240 Ohms. Features a coil power of 600mW and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 53.30mm, width 33.40mm, and height 16.50mm.Manufactured by ELESTA and compliant with ROHS standards. Packaged as BOX for convenience.

SLR222 12VDC RELAY FORCEGUIDED 10A 12VDC (2 Form A/2 Form B) Technical Specifications

• Manufacturer: ELESTA
• RelayType: Relay Forcibly Guided
• Series: SLR4
• MountingType: THT
• ContactForm: 4PST-NO/NC (2 Form A/2 Form B)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent: 50mA
• ContactVoltage: 250VAC/DC
• CoilResistance: 240 Ohms
• CoilPower: 600mW
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 10 Pin
• Length: 53.30mm
• Width: 33.40mm
• Height: 16.50mm
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
