SIR372 24VDC RELAY FORCEGUIDED 10A 24VDC (3 Form A/7 Form B)

SIR372 24VDC RELAY FORCEGUIDED 10A 24VDC (3 Form A/7 Form B) Description

SIR372 24VDC RELAY FORCEGUIDED 10A 24VDC (3 Form A/7 Form B) SIR372 24VDC is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/DC and coil resistance of 440 Ohms. Features a coil power of 1.30W and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 85.50mm, width 20.00mm, and height 32.00mm.Manufactured by ELESTA and compliant with ROHS standards. Packaged as BOX for convenience.

SIR372 24VDC RELAY FORCEGUIDED 10A 24VDC (3 Form A/7 Form B) Technical Specifications

• Manufacturer: ELESTA
• RelayType: Relay Forcibly Guided
• Series: SIR10
• MountingType: THT
• ContactForm: 10PST-NO/NC (3 Form A/7 Form B)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max):
• CoilVoltage: 24VDC
• CoilCurrent: 54.50mA
• ContactVoltage: 250VAC/DC
• CoilResistance: 440 Ohms
• CoilPower: 1.30W
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 22 Pin
• Length: 85.50mm
• Width: 20.00mm
• Height: 32.00mm
• Rohs: ROHS
• Packaging: BOX

---

You can click for product datasheet.
