SFT0905-100 CHOKE COMMON MODE 10uH 1.6A 80m Ohms SMT

SFT0905-100 CHOKE COMMON MODE 10uH 1.6A 80m Ohms SMT Description

SFT0905-100 CHOKE COMMON MODE 10uH 1.6A 80m Ohms SMT The product SFT0905-100 (CHOKE COMMON MODE 10uH 1.6A 80m Ohms SMT) is a high-quality common mode choke designed for efficient noise suppression. Manufactured by CORE MASTER, it features an inductance of 10uH and a DC resistance of 80m Ohms. Built for General Purpose, it is suitable for various applications. The compact design measures 9.20mm x 6.00mm x 5.00mm and operates within a temperature range of N/A. Packaged in TAPE&REEL format, this choke complies with ROHS standards, making it a reliable choice for modern systems.

SFT0905-100 CHOKE COMMON MODE 10uH 1.6A 80m Ohms SMT Technical Specifications

• Manufacturer: CORE MASTER
• Series: SFT
• MountingType: SMT
• Package/Case: Non Standard
• Pitch: None
• Technology: Wire Wound
• Shielding: Shielded
• FilterType: Signal Line Filter
• NumberofLines: 2
• Inductance: 10uH
• Impedance: None
• Current: 1.6A
• Tolerance: +50%/-30%
• DCResistance(DCR): 80m Ohms
• Applications: General Purpose
• Diameter:
• Length: 9.20mm
• Width: 6.00mm
• Height: 5.00mm
• OperationTemperature:
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
