SDC4D28-220M-LF INDUCTOR POWER 22UH 4.7X4.7X3MM SMD

SDC4D28-220M-LF INDUCTOR POWER 22UH 4.7X4.7X3MM SMD Description

SDC4D28-220M-LF INDUCTOR POWER 22UH 4.7X4.7X3MM SMD The SDC4D28-220M-LF is an advanced fixed inductor tailored for high-performance applications. With its INDUCTOR POWER 22UH 4.7X4.7X3MM SMD, this component ensures reliable and efficient power management. Manufactured by COILMASTER, it features compact dimensions of 4.70mm x 4.70mm x 3.00mm, making it ideal for space-constrained designs. Its ability to operate within -40°C ~ +125°C demonstrates its durability and versatility. Compliant with ROHS standards, the SDC4D28-220M-LF reflects a commitment to eco-friendly practices. Packaged as TAPE&REEL, it is the perfect choice for engineers seeking precision, performance, and reliability in their circuits.

SDC4D28-220M-LF INDUCTOR POWER 22UH 4.7X4.7X3MM SMD Technical Specifications

• Manufacturer: COILMASTER
• Series: SDC
• MountingType: SMT
• Package/Case: Non Standard
• Pitch: None
• Technology: Wire Wound
• Shielding: Shielded
• Inductance: 22uH
• CurrentRating: 700mA
• Current-Saturation(Isat):
• Tolerance: ±20%
• DCResistance(DCR): 235m Ohms
• Applications: General Purpose
• Diameter:
• Length: 4.70mm
• Width: 4.70mm
• Height: 3.00mm
• OperationTemperature: -40°C ~ +125°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
