PF0560.334NLT INDUCTOR FIXED 330UH 520MA 1R09

PF0560.334NLT INDUCTOR FIXED 330UH 520MA 1R09 Description

PF0560.334NLT INDUCTOR FIXED 330UH 520MA 1R09 The PF0560.334NLT is an advanced fixed inductor tailored for high-performance applications. With its INDUCTOR FIXED 330UH 520MA 1R09, this component ensures reliable and efficient power management. Manufactured by PULSE, it features compact dimensions of 10.40mm x 10.30mm x 4.00mm, making it ideal for space-constrained designs. Its ability to operate within -40°C ~ +125°C demonstrates its durability and versatility. Compliant with ROHS standards, the PF0560.334NLT reflects a commitment to eco-friendly practices. Packaged as TAPE&REEL, it is the perfect choice for engineers seeking precision, performance, and reliability in their circuits.

PF0560.334NLT INDUCTOR FIXED 330UH 520MA 1R09 Technical Specifications

• Manufacturer: PULSE
• Series: PF
• MountingType: SMT
• Package/Case: Non Standard
• Pitch: None
• Technology: Wire Wound
• Shielding: Shielded
• Inductance: 330uH
• CurrentRating: 520mA
• Current-Saturation(Isat):
• Tolerance: ±25%
• DCResistance(DCR): 1.09 Ohms
• Applications: General Purpose
• Diameter:
• Length: 10.40mm
• Width: 10.30mm
• Height: 4.00mm
• OperationTemperature: -40°C ~ +125°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
