PCN-112D3MHZ,000 RELAY 3A 12VDC SPST-NO THT OEG

PCN-112D3MHZ,000 RELAY 3A 12VDC SPST-NO THT OEG Description

PCN-112D3MHZ,000 RELAY 3A 12VDC SPST-NO THT OEG PCN-112D3MHZ,000 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 277VAC/125VDC - Max and coil resistance of 1.20K Ohms. Features a coil power of 120mW and operates within a temperature range of -30°C~+70°C.Compact design with dimensions: length 20.00mm, width 5.00mm, and height 12.50mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

PCN-112D3MHZ,000 RELAY 3A 12VDC SPST-NO THT OEG Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay General
• Series: PCN
• MountingType: THT
• ContactForm: SPST-NO (1 Form A)
• CoilType: Non Latching
• ContactCurrent(Nom): 3A
• ContactCurrent(Max): 5A
• CoilVoltage: 12VDC
• CoilCurrent: 10mA
• ContactVoltage: 277VAC/125VDC - Max
• CoilResistance: 1.20K Ohms
• CoilPower: 120mW
• OperatingTemperature: -30°C~+70°C
• NumberofPins: 4 Pin
• Length: 20.00mm
• Width: 5.00mm
• Height: 12.50mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
