LFXTAL071268REEL CRYSTAL 16.0000MHZ 10PF SMD

LFXTAL071268REEL CRYSTAL 16.0000MHZ 10PF SMD Description

LFXTAL071268REEL CRYSTAL 16.0000MHZ 10PF SMD LFXTAL071268REEL is a high-performance crystal component that operates at a frequency of 16MHz with a frequency stability of ±100PPM.Features equivalent series resistance (ESR) of 100 Ohms. Compact dimensions: length 2.50mm, width 2.00mm, and height 0.60mm. Supports a temperature range of -40°C~+125°C for reliable performance. Manufactured by IQD with compliance to ROHS standards. Packaged as TAPE&REEL for convenience.

LFXTAL071268REEL CRYSTAL 16.0000MHZ 10PF SMD Technical Specifications

• Manufacturer: IQD
• MountingType: SMT
• Series: CFPX-218
• Package/Case: 4-SMD
• Frequency: 16MHz
• Capacitance: 10pF
• FrequencyTolerance: ±10PPM
• FrequencyStability: ±100PPM
• EquivalentSeriesResistance(ESR): 100 Ohms
• Applications: Automotive(AEC-Q200)
• Diameter:
• Length: 2.50mm
• Width: 2.00mm
• Height: 0.60mm
• OperatingTemperature: -40°C~+125°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
