L-KLS2-306V-5.00-03P-4C TERM.BLK.5.00MM 3P PCB TYPE GREEN

L-KLS2-306V-5.00-03P-4C TERM.BLK.5.00MM 3P PCB TYPE GREEN Description

L-KLS2-306V-5.00-03P-4C TERM.BLK.5.00MM 3P PCB TYPE GREEN L-KLS2-306V-5.00-03P-4C is a reliable and efficient PCB terminal that supports an operating temperature range of -30°C~+120°C. Designed for wire gauges 22-14 AWG (1.5 mm²). Constructed using PBT+UL94V-0 housing, N/A clamps, and Brass+Tin Plated pins for durability. Manufactured by KLS ELECTRONIC with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

L-KLS2-306V-5.00-03P-4C TERM.BLK.5.00MM 3P PCB TYPE GREEN Technical Specifications

• Manufacturer: KLS ELECTRONIC
• Series: KLS2-306V
• Gender: None
• WireTermination: Screw
• NumberofPins: 3 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 3
• Pitch: 5.00mm
• MountingType: THT V/T
• WireEntry: 180°
• ProfileHeight: 10.00mm
• Current: 10.0A
• Voltage: 300V
• OperatingTemperature: -30°C~+120°C
• WireGauge(AWG): 22-14 AWG
• WireGauge(mm²): 1.5 mm²
• HousingMaterial: PBT+UL94V-0
• ClampMaterial: N/A
• PinMaterial: Brass+Tin Plated
• Color: Green
• Side: None
• Rohs: ROHS
• BULK: BULK

---

You can click for product datasheet.
