KMC3S050RY15 THERMISTOR PTC RESETTABLE FUSE 1206 500mA 15V

KMC3S050RY15 THERMISTOR PTC RESETTABLE FUSE 1206 500mA 15V Description

KMC3S050RY15 THERMISTOR PTC RESETTABLE FUSE 1206 500mA 15V The KMC3S050RY15, manufactured by THINKING, is a high-performance PTC resettable fuse designed for thermistor ptc resettable fuse 1206 500ma 15v. It offers reliable overcurrent protection with a maximum voltage rating of 15V. The fuse features a trip time of 100ms, ensuring fast response to overcurrent events. Its compact dimensions of 3.20mm x 1.60mm x N/A allow for easy integration into various applications. Operating within a temperature range of -40°C~+85°C, it performs reliably in diverse environments. As a rohs-compliant product, it meets stringent environmental and safety standards. Packaged in tape&reel format, it ensures secure handling and storage. With its robust design and advanced features, the KMC3S050RY15 is an excellent choice for professionals seeking reliable PTC fuse solutions.

KMC3S050RY15 THERMISTOR PTC RESETTABLE FUSE 1206 500mA 15V Technical Specifications

• Manufacturer: THINKING
• MountingType: SMT
• Package/Case: 1206 (3216 Metric)
• Pitch:
• Resistance(Min): 150m Ohms
• Resistance(Max): 700m Ohms
• Current-Hold: 500mA
• Current-Trip: 1A
• Current(Max): 100A
• Voltage(Max): 15V
• Time-Trip: 100ms
• Applications:
• Diameter:
• Length: 3.20mm
• Width: 1.60mm
• Height:
• OperatingTemperature: -40°C~+85°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
