KF103-5.0-02P-1G CONNECTOR T.B. 2PIN 5.00MM GREEN

KF103-5.0-02P-1G CONNECTOR T.B. 2PIN 5.00MM GREEN Description

KF103-5.0-02P-1G CONNECTOR T.B. 2PIN 5.00MM GREEN KF103-5.0-02P-1G is a reliable and efficient PCB terminal that supports an operating temperature range of -40°C~+105°C. Designed for wire gauges 24-14 AWG (2.5 mm²). Constructed using PA66+UL94V-0 housing, Brass+Ni Plated clamps, and Brass+Tin Plated pins for durability. Manufactured by KAIFENG with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

KF103-5.0-02P-1G CONNECTOR T.B. 2PIN 5.00MM GREEN Technical Specifications

• Manufacturer: KAIFENG
• Series: KF103
• Gender: Male
• WireTermination: Screw
• NumberofPins: 2 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 2
• Pitch: 5.00mm
• MountingType: THT 45°
• WireEntry: 45°
• ProfileHeight: 15.60mm
• Current: 10.0A
• Voltage: 300V
• OperatingTemperature: -40°C~+105°C
• WireGauge(AWG): 24-14 AWG
• WireGauge(mm²): 2.5 mm²
• HousingMaterial: PA66+UL94V-0
• ClampMaterial: Brass+Ni Plated
• PinMaterial: Brass+Tin Plated
• Color: Green
• Side: None
• Rohs: ROHS
• BULK: BULK

---
