JQX-38FV-2Z-DC24V RELAY 30A 24VDC 4PNC 8PIN SOCKET TYPE DRAGON

JQX-38FV-2Z-DC24V RELAY 30A 24VDC 4PNC 8PIN SOCKET TYPE DRAGON Description

JQX-38FV-2Z-DC24V RELAY 30A 24VDC 4PNC 8PIN SOCKET TYPE DRAGON JQX-38FV-2Z-DC24V is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC and coil resistance of 230 Ohms. Features a coil power of 2.50W and operates within a temperature range of -40°C~+70°C.Compact design with dimensions: length 41.00mm, width 38.00mm, and height 55.30mm.Manufactured by ASIA DRAGON and compliant with ROHS standards. Packaged as TUBE for convenience.

JQX-38FV-2Z-DC24V RELAY 30A 24VDC 4PNC 8PIN SOCKET TYPE DRAGON Technical Specifications

• Manufacturer: ASIA DRAGON
• RelayType: Relay Power
• Series: JQX-38FV
• MountingType: Socket
• ContactForm: DPDT (2 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 30A
• ContactCurrent(Max): 40A
• CoilVoltage: 24VDC
• CoilCurrent:
• ContactVoltage: 250VAC/30VDC
• CoilResistance: 230 Ohms
• CoilPower: 2.50W
• OperatingTemperature: -40°C~+70°C
• NumberofPins: 8 Pin
• Length: 41.00mm
• Width: 38.00mm
• Height: 55.30mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
