G6CK-2114P-US-DC12 RELAY GEN PURPOSE DPST 8A 12V

G6CK-2114P-US-DC12 RELAY GEN PURPOSE DPST 8A 12V Description

G6CK-2114P-US-DC12 RELAY GEN PURPOSE DPST 8A 12V G6CK-2114P-US-DC12 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 250VAC/30VDC and coil resistance of 514 Ohms. Features a coil power of 280mW and operates within a temperature range of -25°C~+70°C.Compact design with dimensions: length 20.00mm, width 15.00mm, and height 10.00mm.Manufactured by OMRON and compliant with ROHS standards. Packaged as BULK for convenience.

G6CK-2114P-US-DC12 RELAY GEN PURPOSE DPST 8A 12V Technical Specifications

• Manufacturer: OMRON
• RelayType: Relay Power
• Series: G6C
• MountingType: THT
• ContactForm: DPST-NO/NC (1 Form A/1 Form B)
• CoilType: Latching, Dual Coil
• ContactCurrent(Nom): 8A
• ContactCurrent(Max):
• CoilVoltage: 12VDC
• CoilCurrent: 23.30mA
• ContactVoltage: 250VAC/30VDC
• CoilResistance: 514 Ohms
• CoilPower: 280mW
• OperatingTemperature: -25°C~+70°C
• NumberofPins: 6 Pin
• Length: 20.00mm
• Width: 15.00mm
• Height: 10.00mm
• Rohs: ROHS
• Packaging: BULK

---

You can click for product datasheet.
