DG632-5.0-03P-14-12AH TERM.BLK.5.00MM 3P PCB TYPE GREEN

DG632-5.0-03P-14-12AH TERM.BLK.5.00MM 3P PCB TYPE GREEN Description

DG632-5.0-03P-14-12AH TERM.BLK.5.00MM 3P PCB TYPE GREEN DG632-5.0-03P-14-12AH is a reliable and efficient PCB terminal that supports an operating temperature range of -40°C~+105°C. Designed for wire gauges 28-12 AWG (0.5-2.5 mm²). Constructed using PA66 housing, Copper Alloy+Ni Plated clamps, and None pins for durability. Manufactured by DEGSON with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

DG632-5.0-03P-14-12AH TERM.BLK.5.00MM 3P PCB TYPE GREEN Technical Specifications

• Manufacturer: DEGSON
• Series: DG632
• Gender: Male
• WireTermination: Screw
• NumberofPins: 3 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 3
• Pitch: 5.00mm
• MountingType: THT R/A
• WireEntry: 90°
• ProfileHeight: 15.50mm
• Current: 15.0A
• Voltage: 300V
• OperatingTemperature: -40°C~+105°C
• WireGauge(AWG): 28-12 AWG
• WireGauge(mm²): 0.5-2.5 mm²
• HousingMaterial: PA66
• ClampMaterial: Copper Alloy+Ni Plated
• PinMaterial: None
• Color: Green
• Side: None
• Rohs: ROHS
• BULK: BULK

---

You can click for product datasheet.
