DG500-7.62-02P-12-00AH TERM.BLK.7.62MM 2P PCB TYPE BLUE

DG500-7.62-02P-12-00AH TERM.BLK.7.62MM 2P PCB TYPE BLUE Description

DG500-7.62-02P-12-00AH TERM.BLK.7.62MM 2P PCB TYPE BLUE DG500-7.62-02P-12-00AH is a reliable and efficient PCB terminal that supports an operating temperature range of -40°C~+105°C. Designed for wire gauges 30-12 AWG (1.0-2.5 mm²). Constructed using PA66 housing, Copper Alloy+Ni Plated clamps, and Copper Alloy+Sn Plated pins for durability. Manufactured by DEGSON with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

DG500-7.62-02P-12-00AH TERM.BLK.7.62MM 2P PCB TYPE BLUE Technical Specifications

• Manufacturer: DEGSON
• Series: DG500
• Gender: Male
• WireTermination: Screw
• NumberofPins: 2 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 2
• Pitch: 7.62mm
• MountingType: THT V/T
• WireEntry: 180°
• ProfileHeight: 14.00mm
• Current: 20.0A
• Voltage: 300V
• OperatingTemperature: -40°C~+105°C
• WireGauge(AWG): 30-12 AWG
• WireGauge(mm²): 1.0-2.5 mm²
• HousingMaterial: PA66
• ClampMaterial: Copper Alloy+Ni Plated
• PinMaterial: Copper Alloy+Sn Plated
• Color: Blue
• Side: None
• Rohs: ROHS
• BULK: BULK

---

You can click for product datasheet.
