DG126-7.5-03P-14-89AH TERM.BLK.7.50MM 3P PCB TYPE 0 BOY GREEN

DG126-7.5-03P-14-89AH TERM.BLK.7.50MM 3P PCB TYPE 0 BOY GREEN Description

DG126-7.5-03P-14-89AH TERM.BLK.7.50MM 3P PCB TYPE 0 BOY GREEN DG126-7.5-03P-14-89AH is a reliable and efficient PCB terminal that supports an operating temperature range of -40°C~+105°C. Designed for wire gauges 26-14 AWG (0.5-2.5 mm²). Constructed using PA66 housing, Stainless Steel clamps, and None pins for durability. Manufactured by DEGSON with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

DG126-7.5-03P-14-89AH TERM.BLK.7.50MM 3P PCB TYPE 0 BOY GREEN Technical Specifications

• Manufacturer: DEGSON
• Series: DG126
• Gender: Male
• WireTermination: Screw
• NumberofPins: 3 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 3
• Pitch: 7.50mm
• MountingType: THT R/A
• WireEntry: 90°
• ProfileHeight: 10.90mm
• Current: 10.0A
• Voltage: 300V
• OperatingTemperature: -40°C~+105°C
• WireGauge(AWG): 26-14 AWG
• WireGauge(mm²): 0.5-2.5 mm²
• HousingMaterial: PA66
• ClampMaterial: Stainless Steel
• PinMaterial: None
• Color: Green
• Side: None
• Rohs: ROHS
• BULK: BULK

---

You can click for product datasheet.
