ASO23C-40M-F3T CRYSTAL OSC. 40.000MHZ 3V3 50PPM EXT T&R SMD

ASO23C-40M-F3T CRYSTAL OSC. 40.000MHZ 3V3 50PPM EXT T&R SMD Description

ASO23C-40M-F3T CRYSTAL OSC. 40.000MHZ 3V3 50PPM EXT T&R SMD The product ASO23C-40M-F3T (CRYSTAL OSC. 40.000MHZ 3V3 50PPM EXT T&R SMD) is a high-precision crystal oscillator designed for reliable frequency control. Manufactured by ANSEN, it offers a frequency stability of ±50PPM and operates at a supply voltage of 3.3V. The output type is CMOS/Tristate, making it versatile for various N/A applications. The compact design measures 2.60mm x 2.10mm x 1.00mm and performs reliably within a temperature range of -20°C~+70°C. Packaged in TAPE&REEL format and compliant with ROHS standards, it is an ideal choice for modern electronic systems.

ASO23C-40M-F3T CRYSTAL OSC. 40.000MHZ 3V3 50PPM EXT T&R SMD Technical Specifications

• Manufacturer: ANSEN
• MountingType: SMT
• Series: ASO23C
• Package/Case: 4-SMD
• Frequency: 40MHz
• Capacitance: 15pF
• FrequencyTolerance:
• FrequencyStability: ±50PPM
• SupplyVoltage: 3.3V
• Output: CMOS/Tristate
• Applications:
• Length: 2.60mm
• Width: 2.10mm
• Height: 1.00mm
• OperatingTemperature: -20°C~+70°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
