ANT-5GW-MMG2-SMA-1 RF ANT 5G CELLULAR MAG 1M SMA

ANT-5GW-MMG2-SMA-1 RF ANT 5G CELLULAR MAG 1M SMA Description

ANT-5GW-MMG2-SMA-1 RF ANT 5G CELLULAR MAG 1M SMA The product ANT-5GW-MMG2-SMA-1 (RF ANT 5G CELLULAR MAG 1M SMA) is a versatile RF antenna designed for optimal signal transmission and reception. Featuring a WHIP/STRAIGHT type design with an impedance of 50 Ohm, it supports a wide frequency range of 617MHz to 698MHz, 698MHz to 803MHz, 791MHz to 894MHz, 832MHz to 1.518GHz, 1.525GHz to 1.661GHz, 1.695GHz to 2.2GHz, 2.3GHz to 2.69GHz, 3.3GHz to 4.2GHz, 4.4GHz to 5GHz. The antenna offers a gain of -0.5dBi, 3.4dBi, 3.4dBi, 3.3dBi, 0.7dBi, 3.2dBi, 3.6dBi, 4.7dBi, 2.4dBi and a VSWR of 1.6, 2.3, 2.4, 2.5, 2.8, 3.1, 5.7, ensuring efficient performance. Suitable for N/A, it has a compact height of N/A and operates within a temperature range of N/A. Compliant with ROHS standards, it is packaged in BAG format, making it ideal for modern communication systems.

ANT-5GW-MMG2-SMA-1 RF ANT 5G CELLULAR MAG 1M SMA Technical Specifications

• Manufacturer: LINX
• Gender: SMA MALE
• AntennaType: WHIP/STRAIGHT
• Impedance: 50 Ohm
• FrequencyRange: 617MHz to 698MHz, 698MHz to 803MHz, 791MHz to 894MHz, 832MHz to 1.518GHz, 1.525GHz to 1.661GHz, 1.695GHz to 2.2GHz, 2.3GHz to 2.69GHz, 3.3GHz to 4.2GHz, 4.4GHz to 5GHz
• Gain: -0.5dBi, 3.4dBi, 3.4dBi, 3.3dBi, 0.7dBi, 3.2dBi, 3.6dBi, 4.7dBi, 2.4dBi
• VSWR: 1.6, 2.3, 2.4, 2.5, 2.8, 3.1, 5.7
• Applications:
• Height:
• OperatingTemperature:
• Rohs: ROHS
• Packaging: BAG

---

You can click for product datasheet.
