845H-1C-C-12VDC RELAY POWER 10A 12VDC 1P PCB TYPE

845H-1C-C-12VDC RELAY POWER 10A 12VDC 1P PCB TYPE Description

845H-1C-C-12VDC RELAY POWER 10A 12VDC 1P PCB TYPE 845H-1C-C-12VDC is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 240VAC and coil resistance of 206 Ohms. Features a coil power of 700mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 29.00mm, width 12.70mm, and height 18.50mm.Manufactured by SONG CHUAN CO. and compliant with ROHS standards. Packaged as TUBE for convenience.

845H-1C-C-12VDC RELAY POWER 10A 12VDC 1P PCB TYPE Technical Specifications

• Manufacturer: SONG CHUAN CO.
• RelayType: Relay Power
• Series: 845
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 10A
• ContactCurrent(Max): 12A
• CoilVoltage: 12VDC
• CoilCurrent: 58mA
• ContactVoltage: 240VAC
• CoilResistance: 206 Ohms
• CoilPower: 700mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 5 Pin
• Length: 29.00mm
• Width: 12.70mm
• Height: 18.50mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
