7B-16.000MAAE-T CRYSTAL 16MHz 12pF 30ppm SMD4

7B-16.000MAAE-T CRYSTAL 16MHz 12pF 30ppm SMD4 Description

7B-16.000MAAE-T CRYSTAL 16MHz 12pF 30ppm SMD4 7B-16.000MAAE-T is a high-performance crystal component that operates at a frequency of 16MHz with a frequency stability of ±30PPM.Features equivalent series resistance (ESR) of 40 Ohms. Compact dimensions: length 5.00mm, width 3.20mm, and height 0.90mm. Supports a temperature range of -20°C~+70°C for reliable performance. Manufactured by TXC with compliance to ROHS standards. Packaged as TAPE&REEL for convenience.

7B-16.000MAAE-T CRYSTAL 16MHz 12pF 30ppm SMD4 Technical Specifications

• Manufacturer: TXC
• MountingType: SMT
• Series: 7B
• Package/Case: 4-SMD
• Frequency: 16MHz
• Capacitance: 12pF
• FrequencyTolerance: ±30PPM
• FrequencyStability: ±30PPM
• EquivalentSeriesResistance(ESR): 40 Ohms
• Applications:
• Diameter:
• Length: 5.00mm
• Width: 3.20mm
• Height: 0.90mm
• OperatingTemperature: -20°C~+70°C
• Rohs: ROHS
• Packaging: TAPE&REEL

---

You can click for product datasheet.
