34.51.7.005.0010 RELAY 6A 5V 1PNC SPDT 1 Form C

34.51.7.005.0010 RELAY 6A 5V 1PNC SPDT 1 Form C Description

34.51.7.005.0010 RELAY 6A 5V 1PNC SPDT 1 Form C 34.51.7.005.0010 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 400VAC - Max and coil resistance of 130 Ohms. Features a coil power of nan and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 28.00mm, width 5.00mm, and height 15.00mm.Manufactured by FINDER and compliant with ROHS standards. Packaged as BULK for convenience.

34.51.7.005.0010 RELAY 6A 5V 1PNC SPDT 1 Form C Technical Specifications

• Manufacturer: FINDER
• RelayType: Relay Power Slim
• Series: 34.51
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 6A
• ContactCurrent(Max): 10A
• CoilVoltage: 5VDC
• CoilCurrent: 38.40mA
• ContactVoltage: 400VAC - Max
• CoilResistance: 130 Ohms
• CoilPower:
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 5 Pin
• Length: 28.00mm
• Width: 5.00mm
• Height: 15.00mm
• Rohs: ROHS
• Packaging: BULK

---

You can click for product datasheet.
