146-A-111/03 TERM.BLK.5.08MM 3P PCB TYPE 2 BOY

146-A-111/03 TERM.BLK.5.08MM 3P PCB TYPE 2 BOY Description

146-A-111/03 TERM.BLK.5.08MM 3P PCB TYPE 2 BOY 146-A-111/03 is a reliable and efficient PCB terminal that supports an operating temperature range of -40°C~+100°C. Designed for wire gauges 26-14 AWG (2.5-0.14 mm²). Constructed using PA+V-0 housing, Copper Alloy+Tin Plated clamps, and Nickel Plated Brass pins for durability. Manufactured by WECO with compliance to ROHS standards. Packaged in BULK packaging for secure handling.

146-A-111/03 TERM.BLK.5.08MM 3P PCB TYPE 2 BOY Technical Specifications

• Manufacturer: WECO
• Series: 146-A
• Gender: Male
• WireTermination: Screw
• NumberofPins: 3 Pins
• NumberOfLevel: 1
• PositionsOfLevel: 3
• Pitch: 5.08mm
• MountingType: THT R/A
• WireEntry: 180°
• ProfileHeight: 15.00mm
• Current: 24.0A
• Voltage: 250V
• OperatingTemperature: -40°C~+100°C
• WireGauge(AWG): 26-14 AWG
• WireGauge(mm²): 2.5-0.14 mm²
• HousingMaterial: PA+V-0
• ClampMaterial: Copper Alloy+Tin Plated
• PinMaterial: Nickel Plated Brass
• Color: N/A
• Side: None
• Rohs: ROHS
• BULK: BULK

---

You can click for product datasheet.
