1.3" Inch SPI OLED LCD Module 6 Pin (With GND VCC) White SH1106 Chip

1.3 Inch SPI OLED LCD Module Description

The 1.3 Inch SPI OLED LCD Module is a high-resolution display module equipped with a sharp white monochrome OLED screen powered by the SH1106 driver chip. This module features a resolution of 128x64 pixels and a 6-pin SPI interface (GND, VCC, CLK, DIN, CS, DC), enabling fast communication and seamless integration with microcontrollers such as Arduino, ESP32, and Raspberry Pi. Its compact design and low power consumption make it ideal for IoT devices, embedded systems, and wearable electronics.

1.3 Inch SPI OLED LCD Module Features

• High Contrast Display: Bright white monochrome OLED with a resolution of 128x64 pixels.
• SPI Interface: Enables high-speed communication for responsive performance.
• Energy Efficient: Low power consumption, making it suitable for battery-powered applications.
• Compact and Lightweight: Ideal for portable and space-constrained projects.
• SH1106 Driver Chip: Provides reliable performance and compatibility with various software libraries.

1.3 Inch SPI OLED LCD Module Specifications

• Display Size: 1.3 inches
• Resolution: 128x64 pixels
• Display Type: White monochrome OLED
• Chipset: SH1106
• Interface: SPI (GND, VCC, CLK, DIN, CS, DC)
• Operating Voltage: 3.3V - 5V
• Operating Temperature: -40°C to +85°C
• Dimensions: Compact and lightweight

1.3 Inch SPI OLED LCD Module Applications

• IoT Devices: Displays system statuses, notifications, and real-time data in smart devices.
• Wearable Electronics: Suitable for use in smartwatches, fitness trackers, and portable gadgets.
• Prototyping: Adds graphical displays to experimental and DIY projects.
• Embedded Systems: Enhances microcontroller-based designs with visual output capabilities.
• Educational Use: Perfect for learning and testing SPI and OLED technologies.
