1-1415899-9 RELAY 16A 5VDC SPDT 1 Form C

1-1415899-9 RELAY 16A 5VDC SPDT 1 Form C Description

1-1415899-9 RELAY 16A 5VDC SPDT 1 Form C 1-1415899-9 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 400VAC - Max and coil resistance of 22 Ohms. Features a coil power of 410mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 29.00mm, width 12.70mm, and height 15.70mm.Manufactured by TE (SCHRACK) and compliant with ROHS standards. Packaged as TUBE for convenience.

1-1415899-9 RELAY 16A 5VDC SPDT 1 Form C Technical Specifications

• Manufacturer: TE (SCHRACK)
• RelayType: Relay General
• Series: RZ
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 16A
• ContactCurrent(Max):
• CoilVoltage: 5VDC
• CoilCurrent:
• ContactVoltage: 400VAC - Max
• CoilResistance: 22 Ohms
• CoilPower: 410mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 8 Pin
• Length: 29.00mm
• Width: 12.70mm
• Height: 15.70mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
