1-1393239-4 RT114048 RELAY POWER 12A 48VDC PCB TYPE 5PIN

1-1393239-4 RT114048 RELAY POWER 12A 48VDC PCB TYPE 5PIN Description

1-1393239-4 RT114048 RELAY POWER 12A 48VDC PCB TYPE 5PIN 1-1393239-4 RT114048 is a reliable and efficient general relay that designed for N/A applications with a contact voltage of 400VAC - Max and coil resistance of 5.52K Ohms. Features a coil power of 417mW and operates within a temperature range of -40°C~+85°C.Compact design with dimensions: length 29.00mm, width 12.70mm, and height 15.70mm.Manufactured by TE CONNECTIVITY and compliant with ROHS standards. Packaged as TUBE for convenience.

1-1393239-4 RT114048 RELAY POWER 12A 48VDC PCB TYPE 5PIN Technical Specifications

• Manufacturer: TE CONNECTIVITY
• RelayType: Relay General
• Series: RT1
• MountingType: THT
• ContactForm: SPDT (1 Form C)
• CoilType: Non Latching
• ContactCurrent(Nom): 12A
• ContactCurrent(Max):
• CoilVoltage: 48VDC
• CoilCurrent: 8.70mA
• ContactVoltage: 400VAC - Max
• CoilResistance: 5.52K Ohms
• CoilPower: 417mW
• OperatingTemperature: -40°C~+85°C
• NumberofPins: 5 Pin
• Length: 29.00mm
• Width: 12.70mm
• Height: 15.70mm
• Rohs: ROHS
• Packaging: TUBE

---

You can click for product datasheet.
