0.96" Inch SPI OLED LCD Module + CSpin 7 Pin (With GND VCC) Blue SSD1306 Chip

0.96 Inch SPI OLED LCD Module Description

The 0.96 Inch SPI OLED LCD Module with CSpin is a compact and high-contrast display featuring a bright blue monochrome OLED screen and the reliable SSD1306 driver chip. With a resolution of 128x64 pixels and a 7-pin SPI interface (GND, VCC, CLK, DIN, CS, DC, CSpin), this module provides fast communication and extended control. Ideal for IoT projects, embedded systems, and portable applications, it ensures efficient performance with easy integration into microcontroller platforms such as Arduino, ESP32, and Raspberry Pi.

0.96 Inch SPI OLED LCD Module Features

• High Contrast Display: Blue monochrome OLED with a resolution of 128x64 pixels.
• 7-Pin SPI Interface: Includes CSpin for enhanced control and fast communication.
• Energy Efficient: Designed for low power consumption, perfect for battery-powered devices.
• Compact and Lightweight: Fits easily into space-constrained projects.
• SSD1306 Driver Chip: Reliable performance with wide library support.

0.96 Inch SPI OLED LCD Module Specifications

• Display Size: 0.96 inches
• Resolution: 128x64 pixels
• Display Type: Blue monochrome OLED
• Chipset: SSD1306
• Interface: SPI (GND, VCC, CLK, DIN, CS, DC, CSpin)
• Operating Voltage: 3.3V - 5V
• Operating Temperature: -30°C to +70°C
• Dimensions: Compact and lightweight

0.96 Inch SPI OLED LCD Module Applications

• IoT Devices: Displays sensor data, system status, and notifications in smart systems.
• Wearable Electronics: Used in smartwatches and fitness trackers.
• Prototyping: Ideal for adding graphical interfaces to DIY and experimental projects.
• Embedded Systems: Enhances microcontroller designs with graphical displays.
• Educational Projects: Perfect for learning and experimenting with OLED and SPI technologies.
